EloPOS System i5 Kasseterminal (POS) 21.5" AIO 16GB 256GB Windows 10 IoT Enterprise
EloPOS System i5 - Med I/O Hub Stand - alt-i-én 1 x Core i5 8500T / op til 3.5 GHz - vPro - RAM 16 GB - SSD 256 GB - UHD Graphics 630 - Gigabit Ethernet - Win 10 IoT Enterprise LTSC 64-bit - skærm: LED 21.5" 1920 x 1080 (Full HD) touchscreen - sort
EloPOS-systemet, der drives af Elo Touch Solutions, er designet til at opfylde behovene i detail- og hotelmiljøer. Kernen i systemet er en Intel Core i5-8500T-processor, som sikrer en jævn og effektiv drift, selv i spidsbelastningsperioder. Den 10-punkts multi-touch LED-skærm forbedrer kundeinteraktionerne med sin responsive og intuitive grænseflade.
-
Product no 998644901
Model E417915
Brand Elo TouchSystems
EAN 0843173129440
Weight 11.9 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | EloPOS System i5 - med I/O Hub Stand - alt-i-én Core i5 8500T 2.1 GHz - vPro - 16 GB - SSD 256 GB - LED 21.5" |
| Type | Kasseterminal (POS) - alt-i-én |
| Platformteknologi | Intel vPro Platform |
| Processor | 1 x Intel Core i5 (8. Gen) 8500T / 2.1 GHz (op til 3.5 GHz, (6-core) |
| Processor-socket | LGA1151 Socket |
| Processor, hovedegenskaber | Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cachehukommelse | 9 MB |
| Cache pr. processor | 9 MB |
| RAM | 16 GB (installeret) / 32 GB (maks.) - DDR4 SDRAM - ikke-ECC |
| Controller for lagring | SATA (SATA 6Gb/s) |
| Harddisk | SSD 256 GB - SATA 6Gb/s - M.2 |
| Optisk lagring | Intet optisk drev |
| Monitor | 21.5" - LED - 1920 x 1080 (Full HD) - 16:9 - touchscreen |
| Grafik controller | Intel UHD Graphics 630 |
| Lydudgang | Stereo |
| Netværk | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 5.0 |
| Effekt | AC 120/230 V (50/60 Hz) |
| Med OS | Windows 10 IoT Enterprise LTSC 64-bit Edition |
| Farve | Sort |
| Dimensioner (B x D x H) | 41.64 cm x 8.47 cm x 52.59 cm |
| Vægt | 6 kg |
| Miljømæssige standarder | ENERGY STAR kvalificeret |
| Producentgaranti | Begrænset garanti - 3 år |
| General | |
|---|---|
| Color | Black |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | All-in-one |
| Type | Point of sale terminal |
| Processor / Chipset | |
| Chipset Type | Intel Q370 |
| Clock Speed | 2.1 GHz |
| CPU | Intel Core i5 (8th Gen) 8500T |
| CPU Qty | 1 |
| CPU Socket | LGA1151 Socket |
| Max CPU Qty | 1 |
| Max Turbo Speed | 3.5 GHz |
| Number of Cores | 6-core |
| Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory | |
| Cache Per Processor | 9 MB |
| Installed Size | 9 MB |
| RAM | |
| Configuration Features | 1 x 16 GB |
| Effective Memory Speed | 2666 MHz |
| Features | Unbuffered |
| Form Factor | SO-DIMM 260-pin |
| Installed Size | 16 GB / 32 GB (max) |
| Rated Memory Speed | 2666 MHz |
| Slots | 2 (total) / 1 (empty) |
| Technology | DDR4 SDRAM - non-ECC |
| Hard Drive | |
| Capacity | 1 x 256 GB |
| Interface Type | SATA 6Gb/s |
| SSD Endurance | 160 TB |
| Type | SSD - M.2 |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s |
| Type | 1 x SATA |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Diagonal Size | 21.5" |
| Horizontal Viewing Angle | 178 |
| Image Aspect Ratio | 16:9 |
| Image Brightness | 212.5 cd/m² |
| Image Contrast Ratio | 1000:1 |
| Monitor Features | TouchPro Pro Projected Capacitive (PCAP) technology |
| Monitor Type | LED |
| Native Resolution | 1920 x 1080 (Full HD) |
| Response Time | 14 ms |
| Touchscreen | Yes (10-point multi-touch) |
| Vertical Viewing Angle | 178 |
| Widescreen Display | Yes |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 630 |
| Audio Output | |
| Sound Output Mode | Stereo |
| Speakers Included | 2 x right / left channel |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Features | Intel Active Management Technology (AMT) 11 |
| Wireless LAN Supported | Yes |
| Expansion / Connectivity | |
| Interfaces | 3 x USB 3.0 | 2 x USB 2.0 | 4 x USB 2.0 - micro-USB | 2 x PoweredUSB (12 V) | 1 x PoweredUSB (24 V) | 1 x LAN (Gigabit Ethernet) - RJ-45 | 1 x cash drawer | 1 x headphones | 2 x serial - RJ-45 | 1 x USB-C (27 Watt charging) |
| Miscellaneous | |
| Cables Included | RJ-45 to DB-9 cable |
| Compliant Standards | UL, TUV, VCCI, C-Tick, cUL, CB, CCC, FCC, S Mark, RCM, Mexico NOM |
| VESA Mounting Interface | 75 mm, 100 mm |
| Power | |
| Device Type | Power adapter |
| Installed Qty | 1 |
| Power Consumption Operational | 81 Watt |
| Power Provided | 180 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Operating System / Software | |
| OS Provided | Windows 10 IoT Enterprise LTSC 64-bit Edition |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 7.1 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | |
| Depth | 8.47 cm |
| Dimensions & Weight Details | 41.64 cm - 8.47 cm - 52.59 cm - 6 kg - without stand | 41.64 cm - 25.78 cm - 52.59 cm - 8.9 kg - with stand |
| Height | 52.59 cm |
| Weight | 6 kg |
| Width | 41.64 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 37.5 cm |
| Shipping Height | 54.8 cm |
| Shipping Weight | 11.9 kg |
| Shipping Width | 64.4 cm |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 0 °C |
Forbedrede tilslutningsmuligheder
Med en række USB 3.0-, USB 2.0-, PoweredUSB-, LAN- (Gigabit Ethernet) og serielle porte sikrer dette EloPOS-system problemfri tilslutning og integration med en bred vifte af perifere enheder.
Robust ydeevne
EloPOS-systemet drives af en Intel Core i5-8500T-processor med en clockhastighed på 2,1 GHz og Turbo Boost op til 3,5 GHz samt 6 kerner og Intel Smart Cache og leverer pålidelig og effektiv ydeevne til krævende detailmiljøer.
Alsidig skærm
Med en flad frontramme og en 10-punkts multi-touch LED-berøringsskærm giver dette system en intuitiv og interaktiv brugeroplevelse, hvilket gør det ideelt til en række forskellige detail- og hotelmiljøer.
Sikker og håndterbar
EloPOS-systemet er udstyret med Intel vPro-teknologi og en Trusted Platform Module (TPM 2.0)-sikkerhedschip, der giver avancerede sikkerhedsfunktioner og mulighed for fjernadministration, hvilket sikrer, at dine data er beskyttet, og at dit system er let at vedligeholde.
Omfattende trådløse tilslutningsmuligheder
Med understøttelse af Bluetooth 5.0 og Wi-Fi 802.11a/b/g/n/ac tilbyder dette system hurtige og pålidelige trådløse forbindelser, der muliggør mobile betalinger og reducerer kabelrodet for et renere arbejdsområde.
