ATEN CS1953 KVM / audio / USB switch Desktop

ATEN CS1953 - KVM / audio / USB switch - 3 x KVM / audio / USB - 2 lokalbrugere - desktop

Product no: 998679936
Model: CS1953-AT
EAN: 4719264647529
Brand:
ATEN Technology
Weight: 1.32 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.

Specifications

Produktbeskrivelse
ATEN CS1953 - KVM / audio / USB switch - 3 porte
Enhedstype
KVM / audio / USB switch - 3 porte
Undertype
DisplayPort
Porte
3 x KVM / audio / USB
Antal KVM-brugere
2 lokalbrugere
Egenskaber
Firmware kan opgraderes, HDCP kompatibel, metalkabinet, DP++ teknologi, DisplayPort Alternate-tilstand, USB Power Delivery (op til 45 watt)
Overensstemmelsesstandarder
Power Delivery 3.0
Dimensioner (B x D x H)
7.54 cm x 20.63 cm x 4.4 cm
Vægt
500 g
Specifications

Full specifications

General
Built-in Devices
2-port USB 3.1 Gen 1 hub
Compliant Standards
Power Delivery 3.0
Device Type
KVM / audio / USB switch - 3 ports
Enclosure Type
Desktop
Features
Firmware upgradable, HDCP compliant, metal housing, DisplayPort Dual-Mode technology (DP++), DisplayPort Alternate mode, USB Power Delivery (up to 45 watt)
Keyboard / Mouse Interface
USB
KVM Local Users Qty
2 local users
Max Resolution
4096 x 2160 @ 60 Hz
Ports
3 x KVM / audio / USB
Status Indicators
USB, KVM, audio
Subtype
DisplayPort
Expansion / Connectivity
Interfaces
2 x keyboard (USB) / mouse (USB) Type A console | 1 x DisplayPort console | 1 x microphone mini-jack console | 1 x headphones mini-jack console | 3 x audio mini-jack | 2 x USB 3.1 Gen 1 Type B | 1 x USB-C | 2 x DisplayPort
Power
Power Consumption Operational
5.78 Watt
Power Device
External power adapter
Power Provided
12 V
Miscellaneous
Cables Included
2 x DisplayPort cable | 1 x USB-C cable | 2 x SuperSpeed USB cable | 3 x audio cable
Compliant Standards
DisplayPort 1.2
Included Accessories
Remote port selector switch
Dimensions & Weight
Depth
20.63 cm
Height
4.4 cm
Weight
500 g
Width
7.54 cm
Environmental Parameters
Humidity Range Operating
0 - 80% (non-condensing)
Max Operating Temperature
40 °C
Max Storage Temperature
60 °C
Min Operating Temperature
0 °C
Min Storage Temperature
-20 °C
