ATEN VS381B Video-/audioswitch HDMI

ATEN VS381B - Video-/audioswitch - 3 x HDMI - desktop

Product no: 998581078
Model: VS381B-AT
EAN: 4710469340383
Brand:
ATEN Technology
Weight: 0.15 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.

Specifications

Produktbeskrivelse
ATEN VS381B - video-/audioswitch - 3 porte
Enhedstype
Video-/audioswitch - 3 porte
Undertype
HDMI
Porte
3 x HDMI
Egenskaber
HDCP kompatibel, 3D-support, 7,1 kanals audiosupport, metalkabinet, Dolby Vision HDR support, HDR10+ support, HLG support
Overensstemmelsesstandarder
HDCP 2.2
Dimensioner (B x D x H)
7.9 cm x 7.16 cm x 2.55 cm
Vægt
150 g
Specifications

Full specifications

General
Compliant Standards
HDCP 2.2
Device Type
Video/audio switch - 3 ports
Enclosure Type
Desktop
Features
HDCP compliant, 3D support, 7.1 channel audio support, metal housing, Dolby Vision HDR support, HDR10+ support, Hybrid Log-Gamma (HLG) support
Max Resolution
4096 x 2160 / 3840 x 2160 @ 60 Hz
Max Video Bandwidth
600 MHz
Ports
3 x HDMI
Status Indicators
Port status, power
Subtype
HDMI
Expansion / Connectivity
Interfaces
3 x HDMI input Type A | 1 x HDMI output Type A
Power
Power Consumption Operational
1.46 Watt
Miscellaneous
Cables Included
1 x power DC jack to USB cable
Compliant Standards
Plug and Play
Included Accessories
Wireless remote control, IR receiver
Dimensions & Weight
Depth
7.16 cm
Height
2.55 cm
Weight
150 g
Width
7.9 cm
Environmental Parameters
Humidity Range Operating
0 - 80% (non-condensing)
Max Operating Temperature
40 °C
Max Storage Temperature
60 °C
Min Operating Temperature
0 °C
Min Storage Temperature
-20 °C
