Product no 993171362
Model 40AF0135EU
Brand
Go to brand's website
EAN 0191999788403
Weight 1.39 kg
Produktbeskrivelse | Lenovo ThinkPad Hybrid USB-C with USB-A Dock - dockingstation - USB-C - 2 x HDMI, 2 x DP - GigE |
Produkttype | Dockingstation |
Docking-interface | USB-C |
Videointerfacer | 2 x HDMI, 2 x DP |
Dimensioner (B x D x H) | 21 cm x 8 cm x 3 cm |
Vægt | 475 g |
Lokalisering | Indonesien, Vietnam, Europa |
Netværk | Gigabit Ethernet |
Effekt | Strømforsyningsadapter 135 Watt |
Producentgaranti | 3 års garanti |
Designet for | Miix 520-12IKB; Tablet 10; ThinkPad E480; E580; L380; L380 Yoga; L470; L480; L580; P51s; P52s; T25; T470; T470p; T470s; T480; T480s; T570; T580; X1 Carbon; X1 Tablet; X1 Yoga; X270; X280; ThinkPad Yoga 370 |
General | |
---|---|
Product Type | Docking station |
Width | 21 cm |
Depth | 8 cm |
Height | 3 cm |
Weight | 475 g |
Localization | Indonesia, Vietnam, Europe |
Video | |
Max Resolution Details |
4096 x 2160 - 60 Hz (DisplayPort only)
4096 x 2160 - 60 Hz (HDMI only) 3840 x [email protected], 3840 x [email protected] (DisplayPort1 and DisplayPort2 simultaneously) 3840 x [email protected], 3840 x [email protected] (HDMI1 and HDMI2 simultaneously) 3840 x [email protected], 3840 x [email protected] (DisplayPort and HDMI simultaneously) |
Networking | |
Data Link Protocol | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces |
2 x USB 3.1 Gen 2 - 9 pin USB Type A
1 x USB 3.1 Gen 2 with Always-on charging - 9 pin USB Type A 2 x USB 2.0 - 4 pin USB Type A 1 x USB 3.1 Gen 2 - 24 pin USB-C 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 2 x audio / video - DisplayPort - 20 pin DisplayPort 2 x audio / video - HDMI - 19 pin HDMI Type A 1 x audio - headphones/microphone - mini-phone 3.5 mm 4-pole |
Miscellaneous | |
Cables Included | 1 x USB-C cable with USB-C to USB-A dongle - external |
Features | Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, MAC address pass-through |
Compliant Standards | TUV, VCCI, BSMI, NOM, CB, FCC, SII, KCC, ICES, cULus, Kvalitet, EAC, RCM, LoA |
Power | |
Power Device | Power adapter |
Power Provided | 135 Watt |
System Requirements | |
OS Required | Windows 10 (32/64 bits) |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Dimensions & Weight (Shipping) | |
Shipping Width | 27 cm |
Shipping Depth | 16.5 cm |
Shipping Height | 8.8 cm |
Shipping Weight | 1.35 kg |
Environmental Parameters | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 35 °C |
Compatibility Information | |
Designed For |
Lenovo 13w Yoga 82S1, 82S2
Lenovo IdeaPad 1 14IJL7 82LV Lenovo IdeaPad 1 15IJL7 82LX Lenovo IdeaPad 3 14ADA6 82KQ Lenovo IdeaPad 3 15ALC6 82MF Lenovo IdeaPad 3 15ITL6 82MD Lenovo IdeaPad 5 14ABA7 82SE Lenovo IdeaPad 5 14IAL7 82SD Lenovo IdeaPad Gaming 3 15ARH7 82SB Lenovo IdeaPad Gaming 3 15IAH7 82S9 Lenovo IdeaPad Gaming 3 15IHU6 82MG Lenovo IdeaPad Slim 7 Carbon 14ACN6 82L1 Lenovo K14 Gen 1 21CU Lenovo Lenovo Slim 7 14IAP7 82SX Lenovo ThinkBook 13s G4 IAP 21AR Lenovo ThinkBook 13x G2 IAP 21AT Lenovo ThinkBook 14 G4 ABA 21DK Lenovo ThinkBook 14 G4+ IAP 21CX Lenovo ThinkBook 15 G4 ABA 21DL Lenovo ThinkPad E14 Gen 3 20YF Lenovo ThinkPad E14 Gen 4 21E3, 21EB Lenovo ThinkPad E15 Gen 4 21E6, 21ED Lenovo ThinkPad L13 Gen 2 21AB, 21AC Lenovo ThinkPad L13 Gen 3 21B9 Lenovo ThinkPad L13 Yoga Gen 2 21AD, 21AE Lenovo ThinkPad L13 Yoga Gen 3 21BB Lenovo ThinkPad L14 Gen 3 21C1, 21C2, 21C5, 21C6 Lenovo ThinkPad L15 Gen 3 21C7 Lenovo ThinkPad P1 Gen 4 20Y4 Lenovo ThinkPad P1 Gen 5 21DC Lenovo ThinkPad P14s Gen 3 21AK Lenovo ThinkPad P15v Gen 2 21AA Lenovo ThinkPad P15v Gen 3 21D8, 21D9 Lenovo ThinkPad T14 Gen 3 21AH Lenovo ThinkPad T14s Gen 2 20XF, 20XG Lenovo ThinkPad T14s Gen 3 21BR, 21BS Lenovo ThinkPad T15p Gen 2 21A8 Lenovo ThinkPad T15p Gen 3 21DA Lenovo ThinkPad T16 Gen 1 21BV Lenovo ThinkPad X1 Carbon Gen 10 21CB, 21CC Lenovo ThinkPad X1 Extreme Gen 4 20Y5, 20Y6 Lenovo ThinkPad X1 Nano Gen 2 21E8 Lenovo ThinkPad X1 Yoga Gen 7 21CD, 21CE Lenovo ThinkPad X13 Gen 2 20XH, 20XJ Lenovo ThinkPad X13 Gen 3 21BN Lenovo V14 G2 IJL 82QX Lenovo V14 G2 ITL 82NM Lenovo V15 G2 IJL 82QY Lenovo V15 G2 ITL 82ME Lenovo V15 IML 82NQ Lenovo Yoga Duet 7 13ITL6-LTE 82Q7 Lenovo Yoga Slim 7 Carbon 14ACN6 82L0 Lenovo Yoga Slim 7 Pro 14ACH5 OD 82NK Lenovo Yoga Slim 7 Pro 14IAP7 82SV Lenovo Yoga Slim 7 Pro 16ACH6 82QQ |
