LevelOne POW-2421 60Watt
LevelOne POW-2421 - Strømforsyning (monterbar på DIN rail) - AC 85 - 264 / DC 124 - 370 V - 60 Watt
-
Product no 993998205
Model POW-2421
Brand LevelOne
EAN 4015867206454
Weight 0.19 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | LevelOne POW-2421 - strømforsyning - 60 Watt |
| Enhedstype | Strømforsyning - monterbar på DIN rail |
| Vægt | 190 g |
| Indgangspænding | AC 85 - 264 / DC 124 - 370 V |
| Udgangspænding | 24 V |
| Strømkapacitet | 60 Watt |
| Dimensioner (B x D x H) | 5.25 cm x 9 cm x 5.45 cm |
| General | |
|---|---|
| Device Type | Power supply - DIN rail mountable |
| Power Device | |
| Input Voltage | AC 85 - 264 / DC 124 - 370 V |
| Output Voltage | 24 V |
| Power Capacity | 60 Watt |
| Miscellaneous | |
| Compliant Standards | TUV, EMC, UL 60950-1, IEC 60950-1, EN 60950-1, UL 508, BSMI CNS 14336-1, EN 61558-2-16 |
| Features | Overvoltage protection, overload protection, fanless, short-circuit protection |
| MTBF | 927,600 hours |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -30 °C |
| Dimensions & Weight | |
| Depth | 9 cm |
| Height | 5.45 cm |
| Weight | 190 g |
| Width | 5.25 cm |
