MikroTik RouterBOARD RB1100AHx4 Router 13-port switch Kabling
MikroTik RouterBOARD RB1100AHx4 - Router 13-port switch - 1GbE - monterbar på stativ
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
|
Produktbeskrivelse
|
MikroTik RouterBOARD RB1100AHx4 - router - monterbar på stativ
|
|
Enhedstype
|
Router - 13-port switch (integreret)
|
|
Pakningstype
|
Monterbar på stativ - 1U
|
|
Dataforbindelsesprotokol
|
Ethernet, Fast Ethernet, Gigabit Ethernet
|
|
Præstation
|
Kapacitet: 7,5 Gbps
|
|
Egenskaber
|
PoE, auto-uplink (auto MDI/MDI-X), PoE+, bypass interfacepar, spændingsovervågning
|
|
Overensstemmelsesstandarder
|
IEEE 802.3af, IEEE 802.3at
|
|
Effekt
|
AC 120/230 V
|
|
Dimensioner (B x D x H)
|
44.4 cm x 14.8 cm x 4.7 cm
|
Full specifications
|
General
|
|
|---|---|
|
Built-in Devices
|
microSD card reader
|
|
Compliant Standards
|
IEEE 802.3af, IEEE 802.3at
|
|
Connectivity Technology
|
Wired
|
|
Data Link Protocol
|
Ethernet, Fast Ethernet, Gigabit Ethernet
|
|
Device Type
|
Router - 13-port switch (integrated)
|
|
Enclosure Type
|
Rack-mountable - 1U
|
|
Features
|
Power over Ethernet (PoE), auto-uplink (auto MDI/MDI-X), PoE+, bypass interface pair, voltage monitoring
|
|
Flash Memory
|
128 MB
|
|
Performance
|
Throughput: 7.5 Gbps
|
|
Processor
|
1 x Annapurna Labs Cortex-A15 1.4 GHz
|
|
RAM
|
1 GB
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
13 x 10Base-T/100Base-TX/1000Base-T - RJ-45 | Console: 1 x RS-232C - 9 pin D-Sub (DB-9)
|
|
Power
|
|
|
Installed Qty
|
2 (installed) / 2 (max)
|
|
Power Consumption Operational
|
20 Watt
|
|
Power Device
|
Internal power supply
|
|
Power Redundancy
|
Yes
|
|
Voltage Required
|
AC 120/230 V
|
|
Miscellaneous
|
|
|
Included Accessories
|
Mounting screws, 2 rack mounting ears
|
|
Software / System Requirements
|
|
|
OS Provided
|
MikroTik RouterOS (licence level 6)
|
|
Dimensions & Weight
|
|
|
Depth
|
14.8 cm
|
|
Height
|
4.7 cm
|
|
Width
|
44.4 cm
|
|
Environmental Parameters
|
|
|
Max Operating Temperature
|
70 °C
|
|
Min Operating Temperature
|
-40 °C
|
