Produktbeskrivelse
|
Noctua NH-D9L - processor-køler
|
|
Produkttype
|
Processor-køler
|
|
Pakke Indhold
|
Lav-støjsadapter (L.N.A.), SecuFirm2 Mounting Kit, NT-H1 termisk pasta, NF-A9 PWM premium-blæser
|
|
Kompatabilitet
|
LGA1156 Socket, Socket AM2, Socket AM2+, Socket AM3, LGA1155 Socket, Socket AM3+, LGA2011 Socket, Socket FM1, Socket FM2, LGA1150 Socket, Socket FM2+, LGA2011-3 Socket, Socket AM4, LGA1200 Socket
|
|
Materiale til varmeafleder
|
Aluminium med nikkel belagt kobber base
|
|
Blæser diameter
|
92 mm
|
|
Blæser-højde
|
25 mm
|
|
Blæser med kugleleje
|
SSO2 leje
|
|
Omdrejningshastighed
|
400-2000 rpm
|
|
Luftstrøm
|
36,9 - 46,4 cfm
|
|
Støjniveau
|
16.3 - 22.8 dBA
|
|
Stik
|
4-pins blæser-stikforbindelse
|
|
Egenskaber
|
Varmerør teknologi, Puls-bredde modulation (PWM) support, Soldered joints, 8 kobbervarmerør
|
|
Dimensioner (B x D x H)
|
9.5 cm x 9.5 cm x 11 cm
|
|
Vægt
|
531 g
|
|
Producentgaranti
|
6 års garanti
|
|
Designet for
|
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 Sockets
|
Effective Friday, July 3, 2026, the office will close at 4:30 PM on Fridays. From Monday to Thursday, Sales contact hours remain unchanged from 9:00 AM to 5:00 PM, while contact hours for Accounting, Purchasing, and RMA remain unchanged in general.
To gain full access to our webshop, find our entire product range and see our prices, you need to be logged in.
Log in to your account here or sign up as a customer here.
Noctua NH-D9L Processor-køler 1-pack 92 mm
Noctua NH-D9L - Processor-køler - (for: LGA1156, AM2, AM2+, AM3, LGA1155, AM3+, LGA2011, FM1, FM2, LGA1150, FM2+, LGA2011-3, AM4, LGA1200) - aluminium med nikkel belagt kobber base - 92 mm - for Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 Sockets
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
Full specifications
|
General
|
|
|---|---|
|
Depth
|
9.5 cm
|
|
Height
|
11 cm
|
|
Package Content
|
Low-Noise Adaptor (L.N.A.), SecuFirm2 Mounting Kit, NT-H1 thermal paste, NF-A9 PWM premium fan
|
|
Product Type
|
Processor cooler
|
|
Weight
|
531 g
|
|
Width
|
9.5 cm
|
|
Heatsink & Fan
|
|
|
Air Flow
|
36.9-46.4 cfm
|
|
Air Pressure
|
1.53-2.28 mm
|
|
Compatible With
|
LGA1156 Socket, Socket AM2, Socket AM2+, Socket AM3, LGA1155 Socket, Socket AM3+, LGA2011 Socket, Socket FM1, Socket FM2, LGA1150 Socket, Socket FM2+, LGA2011-3 Socket, Socket AM4, LGA1200 Socket
|
|
Fan Bearing
|
SSO2 bearing
|
|
Fan Diameter
|
92 mm
|
|
Fan Height
|
25 mm
|
|
Features
|
Heat pipe technology, Pulse-width modulation (PWM) support, Soldered joints, 8 copper heatpipes
|
|
Heatsink Dimensions
|
110 mm x 96.5 mm x 95 mm
|
|
Heatsink Material
|
Aluminum with nickel plated copper base
|
|
Noise & Performance Details
|
22.8 dBA / 46.4 cfm at 2000 rpm | 16.3 dBA / 46.4 cfm at 1500 rpm
|
|
Noise Level
|
16.3 - 22.8 dBA
|
|
Power Connector
|
4-pin fan connector
|
|
Power Consumption
|
1.2 W
|
|
Rotation Speed
|
400-2000 rpm
|
|
Start Voltage
|
12 V
|
|
Miscellaneous
|
|
|
Mounting Kit
|
Included
|
|
MTBF
|
150,000 hour(s)
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty: - 6 years
|
