TRENDnet TI-PG62B Switch 6-porte Gigabit PoE+

TRENDnet TI-PG62B - Switch - ikke administreret - 4 x 10/100/1000 (PoE+) + 2 x Gigabit SFP - DIN monterbar på skinne, væg-monterbar - PoE+ (120 W) - DC strøm - TAA-kompatibel

Product no: 992086743
Model: TI-PG62B
EAN: 0710931160963
Brand:
Weight: 0.7 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.

Specifications

Produktbeskrivelse
TRENDnet TI-PG62B - switch - 6 porte - ikke administreret - TAA-kompatibel
Enhedstype
Switch - 6 porte - ikke administreret
Undertype
Gigabit Ethernet
Porte
4 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
PoE-budget
120 W
Præstation
Skift af stofbåndbredde: 12 Gbps<br>Videresendelsespræstation (64-byte pakkestørrelse): 8,9 Mpps
MAC adresse table størrelse
1 K indtastningshukommelse
Jumborammesupport
9KB
Egenskaber
Auto-negotiation, gem og send, halv dupleksmodus, fuld dupleksmodus, overstrømsbeskyttelse, grov, indbygget DIP switch, 1 MB pakkebuffer, 6 KV Electrostatic Discharge Protection, stødresistent, vibrationssikker
Overensstemmelsesstandarder
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Effekt
DC 12 - 56 V
Overskudsspænding
Ja
Dimensioner (B x D x H)
14.3 cm x 10.5 cm x 4.5 cm
Vægt
700 g
TAA kompatibel
Ja
Producentgaranti
Begrænset livtidsgaranti
Specifications

Full specifications

General
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Device Type
Switch - 6 ports - unmanaged
Enclosure Type
DIN rail mountable, wall-mountable
Features
Auto-negotiation, store and forward, half duplex mode, full duplex mode, over-current protection, rugged, built-in DIP switch, 1MB packet buffer, 6 KV Electrostatic Discharge Protection, shock-resistant, vibration-proof
Jumbo Frame Support
9KB
MAC Address Table Size
1K entries
Performance
Switching fabric bandwidth: 12 Gbps | Forwarding performance (64-byte packet size): 8.9 Mpps
PoE Budget
120 W
Ports
4 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
Status Indicators
Power
Subtype
Gigabit Ethernet
Expansion / Connectivity
Interfaces
4 x 1000Base-T RJ-45 PoE+ | 2 x Gigabit LAN SFP
Power
Power Device
External power adapter
Power Redundancy
Yes
Voltage Required
DC 12 - 56 V
Miscellaneous
Compliant Standards
FCC, RoHS, WEEE, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6
Included Accessories
DIN-rail mounting kit, wall mounting kit, removable terminal block
MTBF
510,304 hours
Dimensions & Weight
Depth
10.5 cm
Height
4.5 cm
Weight
700 g
Width
14.3 cm
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Humidity Range Operating
0 - 95% (non-condensing)
Max Operating Temperature
75 °C
Min Operating Temperature
-40 °C

Media
