Ubiquiti UniFi Switch USW-24-POE Switch 24-porte Gigabit PoE++
Ubiquiti UniFi Switch USW-24-POE - Switch - Administreret - 24 x 10/100/1000 (16 PoE+) + 2 x Gigabit SFP - monterbar på stativ, desktop - PoE+ (95 W)
Udvid og strømforsy dit netværk med UniFi PoE Switch, en del af Ubiquiti UniFi Enterprise System.
Product no:
995343460
Model:
USW-24-POE
EAN:
0817882028554
Brand:
Weight:
4.03 kg
Specifications
|
Produktbeskrivelse
|
Ubiquiti UniFi Switch USW-24-POE - switch - 24 porte - Administreret - monterbar på stativ
|
|
Enhedstype
|
Switch - 24 porte - Administreret
|
|
Pakningstype
|
Monterbar på stativ 1U
|
|
Undertype
|
Gigabit Ethernet
|
|
Porte
|
24 x 10/100/1000 (16 PoE+) + 2 x Gigabit SFP
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
PoE-budget
|
95 W
|
|
Præstation
|
Ikke-blokerende båndbredde: 26 Gbps<br>Omkoblingskapacitet: 52 Gbps<br>Videresendelseshastighed: 38.69 Mpps
|
|
Egenskaber
|
12KV ESD Protector, blæserløs, GVRP, auto-uplink (auto MDI/MDI-X), switching, portspejling, sammenlægningstilstand, Jumbo Frames support, datatransport, DPI, Storm Control
|
|
Overensstemmelsesstandarder
|
IEEE 802.3af, IEEE 802.3at, IEEE 802.11x
|
|
Effekt
|
AC 120/230 V (50/60 Hz)
|
|
Dimensioner (B x D x H)
|
44.24 cm x 20 cm x 4.37 cm
|
|
Vægt
|
3 kg
|
|
Producentgaranti
|
1 års garanti
|
Full specifications
|
General
|
|
|---|---|
|
Authentication Method
|
RADIUS
|
|
Built-in Devices
|
1.3" touch screen display
|
|
Compliant Standards
|
IEEE 802.3af, IEEE 802.3at, IEEE 802.11x
|
|
Device Type
|
Switch - 24 ports - managed
|
|
Enclosure Type
|
Desktop, rack-mountable 1U
|
|
Features
|
Flow control, switching, auto-uplink (auto MDI/MDI-X), port mirroring, Deep Packet Inspection (DPI), Jumbo Frames support, fanless, Dynamic VLAN Support (GVRP), 12KV ESD Protector, Storm Control, aggregation mode
|
|
Performance
|
Non-blocking bandwidth: 26 Gbps | Switching capacity: 52 Gbps | Forwarding rate: 38.69 Mpps
|
|
PoE Budget
|
95 W
|
|
Ports
|
24 x 10/100/1000 (16 PoE+) + 2 x Gigabit SFP
|
|
Power Over Ethernet (PoE)
|
PoE++
|
|
Status Indicators
|
Status, PoE, link/activity, link/activity/speed
|
|
Subtype
|
Gigabit Ethernet
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
16 x 1000Base-T RJ-45 PoE+ - 32 W | 8 x 1000Base-T RJ-45 | 2 x Gigabit LAN SFP | 1 x management
|
|
Power
|
|
|
Power Consumption Operational
|
25 Watt
|
|
Power Device
|
Internal power supply
|
|
Power Provided
|
120 Watt
|
|
Voltage Required
|
AC 120/230 V (50/60 Hz)
|
|
Miscellaneous
|
|
|
Compliant Standards
|
IC, FCC, ETSI 300 019-1-4
|
|
Dimensions & Weight
|
|
|
Depth
|
20 cm
|
|
Height
|
4.37 cm
|
|
Weight
|
3 kg
|
|
Width
|
44.24 cm
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - 1 year
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
10 - 90% (non-condensing)
|
|
Max Operating Temperature
|
40 °C
|
|
Min Operating Temperature
|
-5 °C
|
Features
Fiber-forbindelse
SFP-porte muliggør netværksuplinks på op til 1 Gbps.
Blæserløs, lydløs køling
UniFi PoE-switchen har blæserløs, lydløs termisk køling, så den kan placeres i ethvert arbejdsområde.
Switching-ydeevne
UniFi PoE-switchen har videresendelseskapacitet til at behandle trafik på alle porte samtidig ved linjehastighed uden pakketab.
