HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI

HPE Networking Comware 5150EI 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G Switch - Switch - L3 - Administreret - 8 x 10/100/1000Base-T (PoE+) + 2 x 1 Gigabit/10 Gigabit SFP+ (uplink/stacking) + 2 x 1000Base-X SFP - monterbar på stativ - PoE+ (125 W) - BTO

  • Product no 1003471800

    Model S5T54A

    Brand Hewlett Packard Ente

    EAN 0190017788951

    Weight 2.35 kg

  • Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Produktbeskrivelse HPE Networking Comware 5150EI 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G Switch - switch - 8 porte - Administreret - monterbar på stativ
Enhedstype Switch - 8 porte - L3 - Administreret - kan stables
Pakningstype Monterbar på stativ 1U
Undertype Gigabit Ethernet
Porte 8 x 10/100/1000Base-T (PoE+) + 2 x 1 Gigabit/10 Gigabit SFP+ (uplink/stacking) + 2 x 1000Base-X SFP
Power Over Ethernet (PoE) PoE+
PoE-budget 125 W
Præstation Videresendelseskapacitet: 60 Gbps<br>Kapacitet: 44.6 Mpps<br>Latens (1000 Mbps): &lt; 5 µs<br>Latens (10 Gbps): &lt; 3 µs<br>Pakkebufferstørrelse: 1,5 MB<br>Stablende båndbredde: 40 Gbps
Kapacitet Switched virtual interfaces (SVIs): 32<br>IPv4 router: 3000<br>IPv4 værtstabelkapacitet: 2000<br>IPv6 router: 750<br>IPv6 værtstabelkapacitet: 750<br>ACL-poster (indgang/udgang): 1024<br>Virtual Routing and Forwarding (VRF) optegnelser: 32
MAC adresse table størrelse 16K indtastningshukommelse
Jumborammesupport 9KB
Routingprotokol IGMP, OSPF, OSPFv2, OSPFv3, RIP-1, RIP-2
Protokol til fjernadministration CLI, SNMP, Telnet, SNMP 1, SNMP 2, SNMP 3, MIB
Egenskaber Blæserløs, DLDP support, Layer 2 switching, Energy Efficient Ethernet, Address Resolution Protocol, OSPF, MSTP support, PVST+, RPVST+, Rapid Reconfiguration of Spanning Tree (RSTP), datatransport, QoS, sFlow, dynamisk ARP beskyttelse, ikke-blokerende arkitektur
Overensstemmelsesstandarder IEEE 802.1x, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.3x, IEEE 802.3az, IEEE 802.1ad, IEEE 802.3at
Effekt AC 90-264 V
Dimensioner (B x D x H) 26.6 cm x 16 cm x 4.4 cm
Vægt 1.5 kg
Pristype BTO
Producentgaranti Begrænset livtidsgaranti

HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI

The HPE Networking Comware Switch Series 5150 EI is a family of stackable L3 access switches powered by HPE Comware OS delivering scalability and resiliency at a modest TCO for small, medium, and large enterprise campus networks. With 8, 24, and 48 gigabit ports, options for mixed copper and fiber connectivity, and up to 30 watts of 802.3at PoE per port this flexible series is ready to connect your edge clients, servers, and IoT devices. Built-in 10 GbE uplinks and  Intelligent Resilient Fabric (IRF) stacking up to 9-members adds scale, resiliency, and simplification to your access network, enabling network operators to manage the whole stack as a single logical switch. Network visibility, management, and operation tools for this series include standard CLI and the Smart Management Center (SmartMC), embedded and ready to use at no additional cost. The series integrates with HPE Aruba Networking IMC, delivering a centralized point of control for your entire network.
HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI
slide {0} of {1}, zoom in, HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI
slide {0} of {1}, zoom in, HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI
slide {0} of {1}, zoom in, HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI
slide {0} of {1}, zoom in, HPE Networking Comware Switch 8p 10M/100M/1G PoE+ 2p SFP 1G 2p SFP+ 1G/10G 5150EI
Family of stackable L3 access switches with 1 GbE downlinks, 10 GbE uplinks, and support OSPF, EIGRP, ISIS, RIP and routed access. PoE-enabled models deliver up to 30 watts of 802.3at power per port.
8, 24, and 48 port configurations available, supporting up to 176 Gbps of switching capacity and 130 Mpps of forwarding throughput. 24-port fiber option with redundant, dual modular power supplies.
Up to 432 ports of scalability with Intelligent Resilient Fabric (IRF) stacking up to 9-members for link and device aggregation across your network, enhancing redundancy and resource usage.
Standard CLI and Smart Management Center (SmartMC) embedded and ready to use, delivering network visibility, management, and operations at no additional cost.
Energy Efficient Ethernet and energy-saving green design initiatives support your sustainability efforts by automatically reducing power to idle ports and powering down unused ports.
Scalable, Reliable L3 Access Switches

Scalable, Reliable L3 Access Switches

  • The HPE Networking Comware Switch Series 5150 EI delivers scalability and enhances reliability of the network with Intelligent Resilient Framework (IRF) technology. IRF stacking enables virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router.
  • IRF stacking enhances performance and reliability with uninterrupted L2 switching and L3 forwarding and reduces operational complexity with simpler, flatter, and more agile networks.
  • Four fixed 10 GbE uplinks (SFP, SFP+, and 10 GBASE-T) deliver performance for bandwidth intensive applications.
  • Link redundancy with support for Spanning Tree (MSTP, RSTP) and Smart Link protocols for highly available links.
Performance with Quality of Service (QoS)

Performance with Quality of Service (QoS)

  • The HPE Networking Comware Switch Series 5150 EI is engineered with non-blocking architecture for low-latency switching. It supports advanced classifier-based Quality of Service (QoS) to group traffic, set priority levels, and rate limit selected traffic on a port, VLAN, or entire switch.
  • It provides traffic prioritization with supported congestion actions including: strict priority (SP) queuing, weighted round robin (WRR), weighted random early detection (WRED), and SP+WRR queuing and traffic policing with Committed Access Rate (CAR) and line rate.
  • Reduce unwanted network traffic with broadcast control and limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic.
Security with Comprehensive Control

Security with Comprehensive Control

  • The HPE Networking Comware Switch Series 5150 EI supports flexible authentication methods including 802.1X and MAC authentication for greater security and policy-driven application authentication. Per-user access control lists (ACLs) provide identity-driven security and access control.
  • Centralized security policy management and network protection with IMC End User Admission Domination (EAD) which integrates security policies, network access control, and access right control policies to form a cooperative security system.
  • ACLs provide IP Layer 2 to Layer 4 traffic filtering while supporting global ACL, VLAN ACL, port ACL, and IPv6 ACL.
  • Dynamic ARP protection with functions such as ARP Detection and ARP packet validation that block broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data.
  • Enhance security with encryption of access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3, and other features including DHCP protection, IP source guard, and RADIUS/HWTACACS.
Simplified Management and Operations

Simplified Management and Operations

  • The HPE Networking Comware Switch Series 5150 EI supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information; it applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or entire switch.
  • It supports SmartMC, an embedded network management tool with a web-based GUI to simplify operations and facilitate centralized management. It offers features such as configuration backup, software version management and seamless switch replacement.
  • RMON and sFlow™ provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events.

TechnicalSpecifications
Memory and processorCPU: Arm 1.2 GHz Dual Core 2 GB SDRAM, 1 GB Flash, 1.5 MB packet buffer
Latency1GE: < 5 µs
10GE: < 3 µs
Throughput45Mpps
Switching capacity60 Gbps
Stacking capabilities9 members IRF
Management featuresIMC - Intelligent Management Center
Command-line interface
SNMP manager
SmartMC GUI
Input voltageAC: 90V to 290V
Power consumptionIdle: Single AC: 8W Full Load: Single AC: 152W (PoE 125W)
