HPE Aruba Networking CX 5420 Switch
HPE Aruba Networking CX 5420 - Switch - 6-slot - L3 - Administreret - front til ryg-luftstrøm - monterbar på stativ
-
Product no 1002546554
Model S0U59A
Brand Hewlett Packard Ente
EAN 0190017650579
Weight 20.9 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HPE Aruba Networking CX 5420 - switch - 6-slot - Administreret - monterbar på stativ |
| Enhedstype | Switch - L3 - Administreret |
| Pakningstype | Front til ryg-luftstrøm monterbar på stativ 4U |
| Præstation | Omkoblingskapacitet: 960 Gbps<br>Kapacitet: 714 Mpps |
| Kapacitet | IPv4 værtstabelkapacitet: 25600<br>IPv6 værtstabelkapacitet: 25600<br>IPv4 ruter (Unicast): 16384<br>IPv6 ruter (Unicast): 8192<br>IGMP-grupper: 2048<br>MLD-grupper: 2048<br>IPv4 ACL-indgange (ingress): 10233<br>IPv6 ACL-poster (indgang): 2558<br>MAC ACL-indgange (ingress): 10233<br>IPv4 ACL-indgange (egress): 5113<br>IPv6 ACL-poster (udgang): 1278<br>MAC ACL-indgange (egress): 5113 |
| Jumborammesupport | 9198 byte |
| Routingprotokol | OSPF, IGMP, VRRP, statisk IP routing, IGMPv3, statisk IPv6 routing, ECMP, MLDv2, MSTP, RSTP, STP |
| Protokol til fjernadministration | RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP, NTP |
| Egenskaber | Layer 2 switching, sFlow, VRRP support, QoS, UDLD, Rapid PVST+, LACP, MVRP, ToS, BPDU, REST API interface, lag 3 routing, EQS |
| Overensstemmelsesstandarder | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.3bt |
| Effekt | AC 100-127/200-240 V |
| Overskudsspænding | Valgfri |
| Dimensioner (B x D x H) | 44.25 cm x 44.74 cm x 17.41 cm |
| Vægt | 15.73 kg |
| Producentgaranti | Begrænset livtidsgaranti |
HPE Aruba Networking CX 5420 6-slot Switch
The HPE Aruba Networking CX 5420 Switch Series is an intelligent, flexible and modular Layer 3 switch chassis created for today's enterprise small and medium campus, branch enterprise networks with built-in MACsec hardware capability, analytics and automation. The CX 5420 series chassis is part of the CX switching portfolio that provides an enterprise-class access layer solution that is easy-to-deploy, simple, secure and resilient. By combining a modern, fully programmable OS with HPE Aruba Networking Network Analytics Engine (NAE), the CX 5420 series provides industry-leading monitoring and troubleshooting capabilities across the network. A powerful Gen7 ASIC architecture delivers performance and extensive feature support with flexible programmability for the tomorrow's applications. This advanced modular 4U chassis switch offers up to 960 Gbps with low latency, 6 half-width line card slots, VSX live upgrade, and HPE Smart Rate 10GbE up to 90W Class-8 PoE with BGP/OSFP/PIM support.
Powerful, modular, intelligent Layer 3 switch chassis supporting BGP, HPE Aruba Networking Virtual Switching Extension (VSX), and OSPF with robust quality of service (QoS).
Flexibility with 6 half-width modules that allow growth when needed and support for port diversity in a condensed 4RU chassis with redundant MM and PSU.
High performance switching with up to 960 Gbps using 714 Mpps, built-in high availability with HPE Aruba Networking Virtual Switching Extension (VSX) live upgrade and Always-On PoE.
Simplified operations with the common HPE Aruba Networking CX Switch Operating System (AOS-CX) used across the CX portfolio delivering a more consistent, more efficient operator experience.
Easy to manage and simplify configurations with HPE Aruba Networking Central, HPE Aruba Networking Switch Multi-Edit Software, with easy-to-use web GUI or industry-standard CLI.
Automated, unified role-based policies for users, Internet of Things (IoT) and devices with HPE Aruba Networking dynamic segmentation and intelligent monitoring, visibility, and remediation with NAE.
Future-ready with Superior Performance
- The HPE Aruba Networking CX 5420 Switch Series uses the latest Gen7 ASICs, delivering very low latency, increased packet buffering, and adaptive power consumption. All switching and routing are wire‑speed to meet the demands of bandwidth‑intensive applications today and in the future.
- The CX 5420 series is a compact 6 slot (4 RU) supporting a choice of line cards and redundant, half‑width management modules that seamlessly support Wi-Fi 6 and IoT with HPE Smart Rate multi-gigabit and 90W PoE ports.
- High availability with HPE Aruba Networking Virtual Switching Extension (VSX) live upgrade provides high availability, non‑disruptive fast upgrades and simplified management, supporting redundant power supplies and N+1 redundant fans.
- The series provides security-first networking with MACsec1 capable line card modules delivering the enterprise-grade performance and security needs for small and medium campus, branch enterprise networks.
Simplified Operations and Management
- The HPE Aruba Networking CX 5420 Switch Series is based on HPE Aruba Networking CX Switch Operating System (AOS-CX), a modern, database‑driven operating system that automates and simplifies many critical and complex network tasks.
- The CX 5420 series delivers unparalleled visibility with built-in analytics for real-time monitoring and troubleshooting to help fix problems faster. The HPE Aruba Networking Network Analytics Engine (NAE) automatically interrogates and analyzes events that can impact network health.
- REST APIs, Python and CLI‑based agents for advanced telemetry, automation to easily identify, troubleshoot network, system, application and security-related issues. The time series database (TSDB) stores configuration and operational state data, making it available to resolve network issues quickly.
- HPE Aruba Networking Switch Multi-Edit Software introduces automation that allows for rapid network-wide changes, and achieves policy conformance post network updates. Intelligent capabilities include search, edit, validation (including conformance checking), deployment, and audit features.
- HPE Aruba Networking CX Mobile App simplifies connecting, stacking and managing CX 5420 series. Switch information can be imported into HPE Aruba Networking Switch Multi-Edit Software for simplified configuration management and to continuously validate conformance of configurations in the network.
Secure and Scalable Segmentation
- The HPE Aruba Networking CX 5420 Switch Series supports HPE Aruba Networking dynamic segmentation that automatically applies and enforces user, device, and application-aware policies on wired and wireless infrastructures.
- Automated device profiling, role-based access control, and Layer 7 firewall features deliver enhanced visibility and performance for a better overall experience for both IT and end-users alike.
- Dynamic segmentation provides scale and flexibility in network design by allowing the stretching of VLANs and subnets across the entire network with VXLAN overlay fabric which uses group based policy tagging to transport source role.
- Extended-Edge VTEP (EE VTEP) static VXLAN supports EE VTEP persona. Enable flexible L2 Fabric design with scale and consistent architecture with support of Group-Based-Policy and role-to-role security enforcement.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | 6-line card slots up to 160 Gb/s forwarding per slot |
| Memory and processor | 16GB DDR4 SODIMM with ECC, 32GB eMMC Flash memory. 64MB shared packet buffer memory shared dynamically among ports |
| Latency | 2.5 micro sec |
| Throughput | 714 Mpps |
| Switching capacity | 960 Gbps (480 Gbps in + 480 Gbps out) |
| PoE capability | Industry standard IEEE 802.3bt High Power PoE support provides up to 90W of Class 8 PoE power per port to support the latest APs and IoT devices |
| Management features | HPE Aruba Networking Central Network Management HPE Aruba Networking Switch Multi-Edit Software Command-line interface SNMP v2c/v3 RMON |
| Power supply | Supports 4 field replaceable and hot-swappable power supply slots |
| Input voltage | 100‑127/200‑240VAC |
| Power consumption | 1600W @ 200-240Vac, 1000W @ 100-127Vac |
